Surface Resistance Tester/ Wrist Strap Tester/Monitor

<%@LANGUAGE="JAVASCRIPT" CODEPAGE="936"%>
BIJ-0435 Static Fieldmeter
●BPortable compact and lightweight
●Battery condition display(4 stage)
●Bar graph indicates field polarity and intensity
●Auto-ranging digital display
●Multi-function audible alarm
●Auto shut off after 5 minutes
●Easy plate attachment for ion balance measurement
●Includes vinyl storage case.Ground lead.And battery
BIJ-0425 Surface resistivity Tester
●Portable and light weight
●Measure the surface resistance, point to point resistance and point to ground resistance
●Automatically changing test voltages of 10 or 100 volts
●The value is indicated with 12 LED’s in different color, Test result is legible
●9 volts battery provides the power
●Test range is 10E3 to 10E12 ohms
●Comply with the requirement of ANSI/ESD S541,ESD S4.1,ESD7.1,and ANSI/ESD S11.11 international standards
BIJ-0430 Wrist strap on-line monitor
●Earth system of body wrist strap in normal operation;no noise,green light on
●Earth system of body wrist strap in circuit-broken status:buzz noise,redlight glittering
BIJ-0440 Dual Footwear Test/wrist strap tester
Advantage：
●Offering repeatable checks on both rignt and left feet at the same time
●LEDindicate one of the following：High,Pass,or Low
●Standard test range:Wrist strap Range 750KΩ-10MΩ，Foot wear Range 750KΩ-100MΩ
●High and Low resistance’ scan be altered for your relevant country Specification(customer decided)
●Accuracy：±5%
●Weight：4.6kg
●Dimensions of tester：190×138×34mm
●Height of station(adjust):0.6~1.07M(24"~42")
●Power requirement:9V alkaline battery
